| Model | 12" | 30" | 36" | 48" |
|---|---|---|---|---|
| Screen Size | 300 mm | 750 mm | 900 mm | 1,200 mm |
| Output / hr | 2 - 40 Kg depending upon the sieve size & product | 75 - 300 Kg depending upon the sieve size & product | 90 - 300 Kg depending upon the sieve size & product | 10 - 1,000 Kg depending upon the sieve size & product |
| Special Vibro Motor | 0.25 HP | 0.75 HP | 1 HP | 2 HP |
| Overall Dimension (L x W x H) | 400 mm x 400 mm x 900 mm | 900 mm x 900 mm x 1,250 | 1,040 mm x 1,040 x 1,250 | 1,600 mm x 1,400 mm x 1,260 |
